Specifications Description
Standards IEC 62196-1 / IEC 62196-2 (Type 2)
Input / Mounting Type Screw or crimp terminals (crimp)
Power Capacity 7 kW (single-phase supported)
Rated Current 16A / 32A (single-phase)
Operating Voltage 220–250V AC (single-phase)
Protection Class IP54 (unpaired) / IP44 (paired)
UV and Impact Resistance High, suitable for outdoor use
Connection Life >10,000 mechanical connection (plug-in) cycles
Insulation Resistance >1000 MΩ (DC 1000V)
Contact Resistance ≤0.5 mΩ
Overtemperature Detection Active protection with internal temperature sensor
Mounting Compatibility Universal Mounting Plate (UMP)
Thermal Performance Stable operation, low heat buildup
Material Type: High-impact plastic, V0 flame retardant class
Lock Mechanism: Electromechanical locking system (automatic plug locking/release)
Certifications: CE, IEC 62196-2
✅ PRODUCT FEATURES (7 kW – Lock Motorized Version)
🔄 Modular Design:
Provides easy integration according to different needs in the charging infrastructure.

🔒 Enhanced Security – Lock Motorized Mechanism:
The vehicle automatically locks when plugged in. It cannot be removed from the socket until charging is complete or unauthorized intervention occurs. High protection against vandalism and unauthorized use.

🔒 E-Lock System: Electronic locking of the plug-socket connection.

🌡 Heat Detection Sensor:
Provides automatic protection with overtemperature detection.

⚙ Easy Maintenance:
Removable cables and a modular design allow for quick service and replacement.

🌐 Compatibility:
100% compatible with global electric vehicles, especially in the European market (including Type 2 EVs).

🎨 Brand Customization:
Logo printing and custom design coatings are available upon request.

🌿 Environmentally Friendly Production:
Produced with CE-compliant, sustainable materials, and a low environmental impact.

🏭 Application Areas (7 kW – Locking Motor)
🚗 Home AC Chargers
(For individual users seeking additional security)

🏢 Public AC Charging Points
(Locked design prevents unauthorized plug removal)

🏬 Corporate Vehicle Fleets
(Ideal for increasing vehicle security and preventing unauthorized access)

🏗 Smart Housing Projects & Site Parking Lots
(Secure solutions for private vehicle owner use)

🔍 Why QSR ENERGY Sockets? (7 kW – Locking Motor)
✅ High engineering quality and manufacturing precision
✅ Plug security thanks to electromechanical locking
✅ Built-in sensor systems that increase thermal safety
✅ Certified production (IEC:62196 - IATF 16949)
✅ Reliable product that has undergone extensive testing
✅ Support for customized production and brand solutions
