Specifications Description
Standards IEC 62196-1 / IEC 62196-2 (Type 2)
Input / Mounting Type Screw or crimp terminals (crimp)
Power Capacity 7 kW (single-phase supported)
Rated Current 16A / 32A (single-phase)
Operating Voltage 220–250V AC (single-phase)
Protection Class IP54 (unpaired) / IP44 (paired)
UV and Impact Resistance High, suitable for outdoor use
Connection Life >10,000 mechanical connection (plug-in) cycles
Insulation Resistance >1000 MΩ (DC 1000V)
Contact Resistance ≤0.5 mΩ
Overtemperature Detection Active protection with internal temperature sensor
Mounting Compatibility Universal Mounting Plate (UMP)
Thermal Performance Stable operation, low temperature rise
Material Type: High-impact plastic, flame retardant class V0
Certifications: CE, IEC 62196-2
✅ PRODUCT FEATURES (for 7 kW)
🔄 Modular Design:
Easy integration according to different needs in the charging infrastructure.

🌡 Temperature Detection Sensor:
Provides automatic protection with overtemperature detection.

⚙ Easy Maintenance:
Fast service and replacement thanks to plug-in cables.

🌐 Compatibility:
100% compatible with global electric vehicles, especially in the European market (EVs with Type 2 inputs).

🎨 Brand Customization:
Logo printing and custom design coating available upon request.

🌿 Environmentally Friendly Production:
CE-compliant, sustainable material selection and low environmental impact.

🏭 Application Areas (7 kW)
🚗 Home AC Chargers
(Suitable for single-phase infrastructure, ideal for individual users)

🏢 Small-scale public AC charging points
(Shopping mall parking lots, municipal charging points)

🏬 Corporate Vehicle Fleets – Low-power applications

🏗 New Generation Housing Projects
(Smart home and apartment parking systems)

🔍 Why QSR ENERGY Sockets? (For the 7 kW version)
✅ High engineering quality and manufacturing precision
✅ Built-in sensor systems that increase thermal safety
✅ Certified production (IEC:62196 - IATF 16949)
✅ Reliable product that has undergone extensive testing
✅ Support for customized production and brand solutions
