Specifications Description
Standards IEC 62196-1 / IEC 62196-2 (Type 2) Input / Mounting Type Screw or crimp terminals (crimp) Power Capacity 22 kW (three-phase supported) Nominal Current 16A / 32A Operating Voltage 220–250V AC (single phase) / 380–400V AC (three phase) Protection Class IP54 (unpaired) IP44 (paired) E-Lock Mechanism Electronic locking >50,000 cycle life UV and Impact Resistance High, suitable for outdoor use Connection Life >10,000 mechanical connection (plug-in) cycles Insulation Resistance >1000 MΩ (DC) 1000V)
Contact Resistance    ≤0.5 mΩ
Overtemperature Detection    Active protection with internal temperature sensor
Mounting Compatibility    Universal Mounting Plate (UMP)
Thermal Performance    Stable operation, low temperature rise
Material Type    High-impact plastic, V0 flame retardant class
Certifications    CE, IEC:62196-2
✅ PRODUCT FEATURES

🔄 Modular Design: Easy integration according to different needs in the charging infrastructure.

🌡 Temperature Detection Sensor: Provides automatic protection with overtemperature detection.

⚙ Easy Maintenance: Fast service and replacement thanks to plug-in cables.

🌐 Compatibility: 100% compatible with global electric vehicles, especially in the European market.

🎨 Brand Customization: Logo printing and custom design coating available upon request.

🌿 Environmentally Friendly Production: CE-compliant, sustainable material selection.

🔒 E-Lock System: Security locking of plug-socket connections with an electronic lock.

🏭 Application Areas

🚗 Home AC Chargers

🏢 Public AC Charging Stations

🏬 Parking Garages, Shopping Malls, Corporate Fleets

🏗 Next-generation residential and smart city projects

🔍 Why QSR ENERGY Sockets?

High engineering quality and manufacturing precision

Built-in sensor systems that increase thermal safety

Certified manufacturing processes (IEC:62196-IATF 16949)

Extensively tested products

Custom-made production and branding solutions tailored to customer specifications
